Product Overview

Description

Key Features

  • 12" Mid-Bass
  • MAX Power: 1000 Watts
  • RMS Power: 500 Watts
  • Impedance: 8-Ohm
  • Ferrite Magnet
  • 96dB

SPECS

SKU
PRO-X12MBASS
Nominal Diameter
12" / 304.8mm
Nominal Impedance
8 ohms
RMS Power Handing
500 Watts
Maximum Power Handing
1000 Watts
Sensitivity (1w/1m)
96dB
Frequency Response
40Hz - 5KHz
Recommended Hi Pass Crossover
60 Hz



SPECS

Voice Coil Diameter
2.5" / 63.5mm
Voice Coil Former Material
KAPTON
Winding Material
CCA + SV
Basket Material
Steel
Magnet Weight
65 Oz



THIELE & SMALL PARAMETERS

Vas
70.5L / 2.49ft3
Xmax
12.3mm
Fs
54Hz
Qms
10.01
Qes
0.474
Qts
0.453
Re
5.2 ohms


MEASUREMENTS

Overall Diameter
12.1" / 308mm
Front Mount Baffle Cutout
10.9" / 278mm
Mounting Depth
4.88" / 124mm
Overall Depth
5.19" / 132mm
Product Weight
13 lbs

Product Overview

DS18 PRO-X12MBASS

12” Mid-Bass Loudspeaker 1000W MAX 8-Ohm

Unleash the full potential of your stereo system with DS18’s PRO-X12MBASS, a powerhouse of sound that takes your audio experience to new heights.
The PRO-X12MBASS stands tall with a 12" diameter, ensuring a full-bodied sound that fills every corner of your space with remarkable clarity. With a nominal impedance of 8 Ohms, this loudspeaker is built to handle power and deliver stunning performance without compromise.
With a high sensitivity rating of 96 dB, the PRO-X12MBASS stands out as an exceptional performer in its category. Even at lower power levels, the PRO-X12MBASS delivers astonishing sound clarity and detail, ensuring that every note and nuance is faithfully reproduced.
Crafted with precision, the PRO-X12MBASS features a 2.5" / 63.5mm voice coil diameter, constructed with durable KAPTON material for optimal performance and longevity. The steel basket and frame materials enhance its overall durability, ensuring that it can withstand the demands of intense audio sessions. Empowered by a robust 65 oz ferrite magnet, paired with the high powered voice coil the PRO-X12MBASS achieves its maximum potential, and produces a strong punch of mid-bass that will resonate through your entire system.
The frequency response of 40Hz - 5KHz covers a wide range, allowing the PRO-X12MBASS to reproduce both thunderous lows and crystal-clear highs with equal finesse. For seamless integration into your audio setup, a recommended Hi Pass Crossover of 60Hz ensures that the speaker operates at its optimal frequency range, complementing the rest of your system flawlessly.
Get ready to be captivated by the DS18 PRO-X12MBASS - the perfect blend of engineering mastery and audio supremacy. Upgrade your stereo system today and rediscover the true power of music.

Free shipping on orders $100+

FAQs

Please read our FAQs page to find out more.

RMS vs. MAX power — which number do I actually care about?

RMS is what your gear handles continuously; MAX is the short burst it can survive without complaint. Match your amplifier's RMS output to your speakers' RMS rating — sizing off the MAX number is how magic smoke gets released.

What does the IP65 rating on DS18 marine gear actually mean?

It's dust-tight and rated against low-pressure water jets from any direction — built for spray, rain, and the occasional wave over the bow, not for full submersion. If something's going somewhere it could sit underwater, that's a different conversation entirely.

How do I match an amplifier to my speakers without guessing?

Add up the RMS rating of everything the amp will power, and pick an amp whose RMS output (at your speakers' impedance — usually 4-ohm) lands close to that total. Undersized is thin sound; wildly oversized is a fast way to blow a voice coil.

Can I mix marine-grade gear into a standard car audio setup, or the reverse?

You can run marine-grade gear in a car — it's just over-built for that environment, no downside besides cost. Running non-weatherproof car audio gear in an open UTV or boat is the direction that causes problems.

What gauge wiring kit do I need?

It scales with your amp's power draw and the length of the run — DS18's OFC kits come in 4-gauge and 8-gauge for a reason. Undersized wiring on a high-draw system is a voltage-drop and heat problem waiting to happen; when in doubt, size up.
