Product Overview

DS18 PRO-DN22PY.8

2” Throat Bolt-On Compression Driver (2” Polyimide Voice Coil / 8-Ohm)

Get superior sound with DS18’s PRO-DN22PY.8, an 8-ohm 2" high-power compression driver designed to deliver crystal-clear sound across mid-to-high frequencies, transforming your car’s sound system into an audiophile's dream. Handling an AES power of 200W / Program power of 400W / and a peak power of 800W, the PRO-DN22PY.8 stands as a titan in car audio upgrades, ensuring you experience every note with unparalleled clarity and volume.

The DS18 PRO-DN22PY.8 offers a seamless bolt-on installation, making it a perfect fit for serious automotive sound enhancements. Its professional-grade design features a robust 2" throat diameter and 8-ohm impedance, providing seamless integration into high-performance setups. The lightweight yet powerful neodymium magnet speaker and polyimide voice coil are crafted to sustain the demands of high-output audio systems, ensuring durability without sacrificing performance.

With an impressive frequency response ranging from 630Hz to 12.5kHz and a high sensitivity of 109 dB, this driver delivers exceptional sound output with minimal power usage. Its compact dimensions—4.4" overall diameter and 2.2" depth—allow for versatile installation, providing you with the flexibility you need to customize their setup without compromise.

DS18’s PRO-DN22PY.8 is tailored for you to get more from your sound system. Upgrade today and feel the difference that expert engineering and premium materials can make in your listening experience.



Specifications

SKU
PRO-DN22PY.8
Throat Diameter
2" / 50.8mm
Installation Type
Bolt-On
Nominal Impedance
8 Ohms
AES Power Handling
200W
Program Power Handling
400W
Peak Power Handling
800W
Sensitivity (1w/1m)
109dB
Frequency Response
630Hz-12.5KHz
Recommended Hi Pass Crossover
800Hz
Sold in Pair or Single
Single


Body / Features

Filter (Bass Blocker)
10Uf/100V
Body Material
Aluminum
Body Color / Finish
Black / Machined


Motor

Voice Coil Diameter
2" / 50.8mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Diaphragm Material
Polyimide
Magnet Material
Neodymium
Magnet Weight
9.9 Oz


Measurement

Overall Diameter
4.4" / 112mm
Overall Depth
2.2" / 56mm
Bolt Pattern/Type
4xM6 - 4" /102mm
