DS18 GTX1XL 3.75" Die-Cast Compression Neodymium Super Bullet Tweeter with 1.3" Aluminum Voice Coil — 160W RMS, 4-Ohm
Product Overview
Description
DS18 GTX1XL 3.75" Die Cast Compression Neodymium Super Bullet Tweeter 320 Watts (Peak) 1.3" Aluminum 4-Ohm Vc
Step into a world of audio perfection with DS18's GTX1XL, the pinnacle of neodymium tweeters. The GTX1XL boasts a massive 3.75-inch die-cast compression neodymium super bullet design. With an astounding MAX power handling of 320W, it's no wonder this tweeter is highly regarded among our competitive audience. With a sensitivity of 100dB and a frequency response ranging from 2.5kHz to 20kHz, the GTX1XL ensures that no detail escapes your ears.
Crafted with precision and finesse, the housing of the GTX1XL is cast from high-strength aluminum, creating a sturdy enclosure that complements your car's interior and protects your investment. One of the standout features is its high precision 1.3-inch aluminum voice coil, delivering unmatched performance and ensuring every note is reproduced with stunning clarity and detail.
Versatility is at the heart of the GTX1XL's design. These super tweeters can be mounted anywhere you have space for them, giving you the freedom to experiment and create the perfect soundstage in your vehicle.
Highlights
- 3.75" die-cast compression neodymium super bullet tweeter — 160W RMS, 320W peak, 4-Ohm.
- High-precision 1.3" aluminum voice coil with CCAW winding.
- High-strength die-cast aluminum housing in a black/red finish.
- Easily disassembled and repaired on the spot in about 60 seconds (replacement diaphragm: GTX1XLVC).
- Mounts in traditional or unconventional locations — 2.95" baffle cutout, 1.73" mounting depth.
- Sold individually (single).
Technical Details
| Model: | GTX1XL |
| Nominal Diameter | 3.75" / 95mm |
| Nominal Impedance | 4 Ohm |
| Peak Power Handling | 320 Watts |
| Program Power Handling | 160 Watts |
| AES Power Handling | 80 Watts |
| Sensitivity (1w/1m) | 100 db |
| Frequency Response | 2.5 K - 20 KHz |
| Recommended Hi Pass Crossover | 2.5 KHz |
| Pair or Single | Single |
Motor
| Voice Coil Diameter | 1.3" / 33.5mm |
| Voice Coil Former Material | KSV |
| Winding Material | CCAW |
| Diaphragm Material | Aluminum |
| Magnet Material | Neodymium |
| Magnet Weight | 1.45 Oz |
| Body Material | Aluminum |
| Body Color / Finish | Black/Red |
Measurement
| Overall Diameter | 3.75" / 95mm |
| Overall Depth | 2.24" / 57mm |
| Front Mount Baffle Cutout | 2.95" / 73mm |
| Mounting Depth | 1.73" / 44mm |
| Gross Single Unit Weight (lb) | 1.5 |
| Single Unit Box Dimensions W x L x H (Inches) | 4.75 x 4.25 x 2.87 |
| Quantity of Units in Master Carton | 24 |
| Gross Master Carton Weight (lb) | 26.5 |
| Master Carton Dimensions W x L x H (Inches) | 22 x 10.25 x 6.25 |
