Product Overview

Description

SPECS

SKU
X1
Class
Class-D / Digital
Channels
1
Total Watts Peak
900W
RMS Power @ 4 Ohm
140W x 1 CH
RMS Power @ 2 Ohm
220W x 1 CH
RMS Power @ 1 Ohm
300W x 1 CH
Frequency Response
20Hz-500H
Signal/noise Ratio
>90 dB
Efficiency @ 4 Ohm
>80%


SPECS

Damping Factor
>200
THD %
<0.2%
Low Level Input Range
0.2-5V
Selectable X-Over
Fixed LPF
X-Over Filter Range
50HZ-250Hz
Bass Boost Range
0-18 dB
Bass Boost Frequency
40 Hz
Infrasonic Filter
10-55Hz
Phase Selector
0 - 180 Degrees
Minimum Impedance
1 Ohm


SPECS

Led Indicator
Power/Protection
Power Input Size
12 GA
Fuse Rating
30 A
Remote Level Control
Yes - Dash Mount
Thermal Protection
Yes
Over-load Protection
Yes
DC Output Protection
Yes
Short Circuit Output Protection
Yes
Voltage Input Protection
Yes
Dimensions L x W x H (inches)
5.54 x 3.24 x 1.37"

Free shipping on orders $100+

FAQs

Please read our FAQs page to find out more.

RMS vs. MAX power — which number do I actually care about?

RMS is what your gear handles continuously; MAX is the short burst it can survive without complaint. Match your amplifier's RMS output to your speakers' RMS rating — sizing off the MAX number is how magic smoke gets released.

What does the IP65 rating on DS18 marine gear actually mean?

It's dust-tight and rated against low-pressure water jets from any direction — built for spray, rain, and the occasional wave over the bow, not for full submersion. If something's going somewhere it could sit underwater, that's a different conversation entirely.

How do I match an amplifier to my speakers without guessing?

Add up the RMS rating of everything the amp will power, and pick an amp whose RMS output (at your speakers' impedance — usually 4-ohm) lands close to that total. Undersized is thin sound; wildly oversized is a fast way to blow a voice coil.

Can I mix marine-grade gear into a standard car audio setup, or the reverse?

You can run marine-grade gear in a car — it's just over-built for that environment, no downside besides cost. Running non-weatherproof car audio gear in an open UTV or boat is the direction that causes problems.

What gauge wiring kit do I need?

It scales with your amp's power draw and the length of the run — DS18's OFC kits come in 4-gauge and 8-gauge for a reason. Undersized wiring on a high-draw system is a voltage-drop and heat problem waiting to happen; when in doubt, size up.
