Product Overview

Description

Product Overview

DS18 PRO-X6BM

6.5” Mid-Range Loudspeaker With Bullet 250W RMS 8-Ohm

Introducing DS18’s PRO-X6BM, the pinnacle of audio excellence.

Renowned for its exceptional midrange and crystal-clear high frequencies, the PRO-X6BM delivers a high-quality audio experience that will transport you to the front row of your personally curated concert.

One of the standout features of the PRO-X6BM is its revamped 1.5" voice coil, designed to effortlessly handle high heat temperatures. Now you can indulge in your favorite tunes at high volumes for extended periods without worrying about damaging your precious speakers.

With an impressive 96dB sensitivity, these speakers allow you to crank up the volume without compromising on sound quality. Experience richer and more accurate tones across the 100Hz to 12KHz frequency range, revealing nuances in your music that will captivate any discerning listener.

But it doesn't stop there – the PRO-X6BM speakers are built to last. With a magnet weight of 30 oz and a manageable mounting depth of 2.58", these speakers prove their durability time and time again, ensuring years of unrivaled audio performance.

Upgrade with confidence – choose DS18’s PRO-X6BM and embark on a musical adventure like never before. Order yours today and let the music speak for itself.

SPECS

SKU
PRO-X6BM
Nominal Diameter
6.5" / 165mm
Nominal Impedance
4 or 8 ohms
RMS Power Handing
250 WATTS
Maximum Power Handing
500 WATTS
Sensitivity (1w/1m)
96dB
Frequency Response
100Hz - 12KHz
Recommended Hi Pass Crossover
120Hz


SPECS

Voice Coil Diameter
1.5 " / 38.6mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Basket Material
Steel
Magnet Weight
30 oz


THIELE & SMALL PARAMETERS

Vas
2.96L / 0.104ft3
Xmax
7.8mm
Fs
170Hz
Qms
7.48
Qes
0.653
Qts
0.634
Re
5.2 ohms


MEASUREMENTS

Overall Diameter
6.57" / 167mm
Front Mount Baffle Cutout
5.7" 145mm
Mounting Depth
2.58" / 65.5mm
Overall Depth
2.8" / 71.3mm
Product Weight
5.5 lbs
Product Dimensions
7.3 x 7.3 x 3.25
M/C Weight
43.5 lbs
M/C Dimensions
15.25 x 15.25 x 7.5
M/C QTY
8

Free shipping on orders $100+

FAQs

Please read our FAQs page to find out more.

RMS vs. MAX power — which number do I actually care about?

RMS is what your gear handles continuously; MAX is the short burst it can survive without complaint. Match your amplifier's RMS output to your speakers' RMS rating — sizing off the MAX number is how magic smoke gets released.

What does the IP65 rating on DS18 marine gear actually mean?

It's dust-tight and rated against low-pressure water jets from any direction — built for spray, rain, and the occasional wave over the bow, not for full submersion. If something's going somewhere it could sit underwater, that's a different conversation entirely.

How do I match an amplifier to my speakers without guessing?

Add up the RMS rating of everything the amp will power, and pick an amp whose RMS output (at your speakers' impedance — usually 4-ohm) lands close to that total. Undersized is thin sound; wildly oversized is a fast way to blow a voice coil.

Can I mix marine-grade gear into a standard car audio setup, or the reverse?

You can run marine-grade gear in a car — it's just over-built for that environment, no downside besides cost. Running non-weatherproof car audio gear in an open UTV or boat is the direction that causes problems.

What gauge wiring kit do I need?

It scales with your amp's power draw and the length of the run — DS18's OFC kits come in 4-gauge and 8-gauge for a reason. Undersized wiring on a high-draw system is a voltage-drop and heat problem waiting to happen; when in doubt, size up.

Didn’t find your answer?

Don't hestitate to contact us
