Product Overview

DS18 PRO-X6BM

6.5” Mid-Range Loudspeaker With Bullet 250W RMS 8-Ohm

Introducing DS18’s PRO-X6BM, the pinnacle of audio excellence.

Renowned for its exceptional midrange and crystal-clear high frequencies, the PRO-X6BM delivers a high-quality audio experience that will transport you to the front row of your personally curated concert.

One of the standout features of the PRO-X6BM is its revamped 1.5" voice coil, designed to effortlessly handle high heat temperatures. Now you can indulge in your favorite tunes at high volumes for extended periods without worrying about damaging your precious speakers.

With an impressive 96dB sensitivity, these speakers allow you to crank up the volume without compromising on sound quality. Experience richer and more accurate tones across the 100Hz to 12KHz frequency range, revealing nuances in your music that will captivate any discerning listener.

But it doesn't stop there – the PRO-X6BM speakers are built to last. With a magnet weight of 30 oz and a manageable mounting depth of 2.58", these speakers prove their durability time and time again, ensuring years of unrivaled audio performance.

Upgrade with confidence – choose DS18’s PRO-X6BM and embark on a musical adventure like never before. Order yours today and let the music speak for itself.



SPECS

SKU
PRO-X6BM
Nominal Diameter
6.5" / 165mm
Nominal Impedance
4 or 8 ohms
RMS Power Handing
250 WATTS
Maximum Power Handing
500 WATTS
Sensitivity (1w/1m)
96dB
Frequency Response
100Hz - 12KHz
Recommended Hi Pass Crossover
120Hz


SPECS

Voice Coil Diameter
1.5 " / 38.6mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Basket Material
Steel
Magnet Weight
30 oz


THIELE & SMALL PARAMETERS

Vas
2.96L / 0.104ft3
Xmax
7.8mm
Fs
170Hz
Qms
7.48
Qes
0.653
Qts
0.634
Re
5.2 ohms


MEASUREMENTS

Overall Diameter
6.57" / 167mm
Front Mount Baffle Cutout
5.7" 145mm
Mounting Depth
2.58" / 65.5mm
Overall Depth
2.8" / 71.3mm
Product Weight
5.5 lbs
Product Dimensions
7.3 x 7.3 x 3.25
M/C Weight
43.5 lbs
M/C Dimensions
15.25 x 15.25 x 7.5
M/C QTY
8
