Product Overview

Description

SPECS

SKU
HOOL-X15DHE
Nominal Diameter
15” / 381mm
Nominal Impedance
1+1, 2+2, or 4+4 ohms
RMS Power Handling
4000W
MAX Power Handling
6000W
Sensitivity (1w/1m)
88.2dB
Frequency Response
16-500Hz
Recommended Lo Pass Crossover
80Hz


MOTOR

Voice Coil Diameter
4” / 99.8mm
Voice Coil Former Material
Black Aluminum
Winding Material
CCAW
Cone Material
Non-Pressed Paper
Dust Cap Material
Carbon Fiber
Surround Material
Foam
Basket Material
Aluminum
Basket Color/Finish
Gloss Black with Machined Aluminum
Magnet Material
Ferrite
Magnet Weight
500 OZ
Displacement Volume
9.1 L / 0.32 ft3


THIELE & SMALL PARAMETERS

Equivalent Volume
61.93 L / 2.18 ft3
Free Air Resonance
26 Hz
Mechanical Factor
4.98
Electrical Factor
0.513
Total Factor
0.402
Moving Mass
478.64 g
Compliance
0.025 mm/N
Bl Factor
15.83
Voice Coil Inductance
2.517 mH
Diaphragm Area
754.77 cm²
DC Resistance
1.9+1.9 ohms
Efficiency Bandwidth Product
50.6


RECOMMENDED ENCLOSURES

Sealed Internal Volume
35.4L / 1.25ft3
Sealed Box Output Response
45Hz
Ported Internal Volume
70.8L / 2.5ft3
Port Size *Square (W x H x Long)
2.47" x 15" x 37" / 62.7 x 381 x 939.8 mm
Port Tunning Frequency
30Hz
Ported Box Output Response
26.5Hz


MEASUREMENT

Overall Diameter
15.56” / 395mm
Overall Depth
13.31” / 338mm
Front Mount Baffle Cutout
14.10” / 358mm
Mounting Depth
11.19” / 284mm
Motor Diameter
9.96” / 253mm
Product Weight (lb)
89
