Product Overview

Description

Key Features

  • Compact 4-channel full-range Class-D amplifier
  • RMS Power: 4 x 120W @ 4Ω, 4 x 200W @ 2Ω, 4 x 300W @ 1Ω
  • Bridged Power: 2 x 350W @ 4Ω | 2 x 500W @ 2Ω
  • Selectable HPF / LPF / Full crossover
  • Bass Boost: 0–12dB at 50Hz
  • Smart cooling fan + 4-layer PCB
  • Power, Protect, Clip LED indicators
  • Blue finish
  • Sold as: single (each)

Product Overview

The DS18 FRP-1.2K4-BL delivers serious power for high-efficiency performance across your entire system: this compact 4-channel amp drives mids, highs, or subs with clarity and punch — all while staying cool under pressure. Stable at 1-Ohm per channel or 2-Ohm bridged, it adapts to your build, and fully variable HPF, LPF, and full-range crossover options plus up to 12dB of bass boost at 50Hz give you full control of your sound. Thanks to its digital Class D design, Tiffany RCA terminals, smart cooling fan, and surface-mount tech, the FRP-1.2K4 stays efficient and clean while pushing up to 1200W RMS.

SPECS

SKU FRP-1.2K4-BL
RMS Power @ 4 ohms 4 x 120W
RMS Power @ 2 ohms 4 x 200W
RMS Power @ 1 ohm 4 x 300W
RMS Power @ 4 ohm Bridge 2 x 350W
RMS Power @ 2 ohm Bridge 2 x 500W
Frequency Response 10Hz-20KHz
Signal to Noise Ratio 90dB
Efficiency @ 4ohm 97%
Damping Factor 90
Input Impedance 10KΩ
Channel Separation 50dB
Total Harmonic Distortion (THD) 0.5%
Low Level Input Range 400mv-6V
High Level Input No
Selectable X-Over Yes, HPF/FULL/LPF
X-Over Filter Range 10Hz-2KHz
Bass Boost Range 0-12dB
Bass Boost Frequency 50Hz
Phase Selector No
Amplifier Class Digital
Amplifier Type Full-Range Multi-Channel
Number of Channels 4CH
Minimum Impedance 1ohm St / 2ohm Bridge
LED Indicator Power / Protect / Clipping
Power Input Terminal Size 4GA
Fuse Size (Recommended) 140A
Cooling Fan Yes (Smart Cooling x 1)
Voltmeter No
Thermal Protection Yes
Over-Load Protection Yes
DC Output Protection Yes
Short Circuit Output Protection Yes
Voltage Input Protection Yes
Clipping Protection Yes
Body Color / Finish Blue
Compact Size to Easy Installation Yes
4-Layer PCB Design Yes
Surface Mount Component Technology Yes
Audio Precision Quality Control Yes
Tiffany RCA Terminal Yes
LED Clip Indicator Yes
Metal Knobs with Click Steps Yes
Input Selector Yes (2ch/4ch)
Remote Level Control w/ Clip Indicator No
Remote Level w/ Voltmeter No
Overall Length 7.2" / 183mm
Overall Width 5.5" / 140mm
Overall Height 2.4" / 63.5mm
Heatsink Length 6" / 152mm
Gross Weight 1.6Kg
Sold As Single

Free shipping on orders $100+

FAQs

Please read our FAQs page to find out more.

RMS vs. MAX power — which number do I actually care about?

RMS is what your gear handles continuously; MAX is the short burst it can survive without complaint. Match your amplifier's RMS output to your speakers' RMS rating — sizing off the MAX number is how magic smoke gets released.

What does the IP65 rating on DS18 marine gear actually mean?

It's dust-tight and rated against low-pressure water jets from any direction — built for spray, rain, and the occasional wave over the bow, not for full submersion. If something's going somewhere it could sit underwater, that's a different conversation entirely.

How do I match an amplifier to my speakers without guessing?

Add up the RMS rating of everything the amp will power, and pick an amp whose RMS output (at your speakers' impedance — usually 4-ohm) lands close to that total. Undersized is thin sound; wildly oversized is a fast way to blow a voice coil.

Can I mix marine-grade gear into a standard car audio setup, or the reverse?

You can run marine-grade gear in a car — it's just over-built for that environment, no downside besides cost. Running non-weatherproof car audio gear in an open UTV or boat is the direction that causes problems.

What gauge wiring kit do I need?

It scales with your amp's power draw and the length of the run — DS18's OFC kits come in 4-gauge and 8-gauge for a reason. Undersized wiring on a high-draw system is a voltage-drop and heat problem waiting to happen; when in doubt, size up.
